MCH6342-TL-W 数据手册
其他文档
MCH6342 5 pages
技术规格
- RoHS: true
- Type: P Channel
- Category: Triode/MOS Tube/Transistor/MOSFETs
- Datasheet: onsemi MCH6342-TL-W
- Power Dissipation (Pd): 1.5W
- Drain Source Voltage (Vdss): 30V
- Continuous Drain Current (Id): 4.5A
- Gate Threshold Voltage (Vgs(th)@Id): 1.3V@1mA
- Drain Source On Resistance (RDS(on)@Vgs,Id): 73mΩ@4.5V,2A
- Package: SC-88FL(MCPH-6)
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- FET Type: P-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 30V
- Current - Continuous Drain (Id) @ 25°C: 4.5A (Ta)
- Drive Voltage (Max Rds On, Min Rds On): 1.8V, 4.5V
- Rds On (Max) @ Id, Vgs: 73mOhm @ 2A, 4.5V
- Vgs(th) (Max) @ Id: 1.3V @ 1mA
- Gate Charge (Qg) (Max) @ Vgs: 8.6nC @ 4.5V
- Vgs (Max): ±10V
- Input Capacitance (Ciss) (Max) @ Vds: 650pF @ 10V
- FET Feature: -
- Power Dissipation (Max): 1.5W (Ta)
- Operating Temperature: 150°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: SC-88FL/MCPH6
- Package / Case: 6-SMD, Flat Leads
- Base Part Number: MCH63
- detail: P-Channel 30V 4.5A (Ta) 1.5W (Ta) Surface Mount SC-88FL/MCPH6
