دیتاشیت 2SC5964-TD-H
مشخصات دیتاشیت
| نام دیتاشیت | 2SA2125/2SC5964 |
|---|---|
| حجم فایل | 326.892 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 6 |
دانلود دیتاشیت 2SA2125/2SC5964 |
2SA2125/2SC5964 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
- Datasheet: onsemi 2SC5964-TD-H
- Transistor Type: NPN
- Operating Temperature: +150°C@(Tj)
- Collector Current (Ic): 3A
- Power Dissipation (Pd): 3.5W
- Transition Frequency (fT): 380MHz
- DC Current Gain (hFE@Ic,Vce): 200@100mA,2V
- Collector Cut-Off Current (Icbo): 1uA
- Collector-Emitter Breakdown Voltage (Vceo): 50V
- Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib): 190mV@2A,100mA
- Package: SOT-89
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Current - Collector (Ic) (Max): 3A
- Voltage - Collector Emitter Breakdown (Max): 50V
- Vce Saturation (Max) @ Ib, Ic: 290mV @ 100mA, 2A
- Current - Collector Cutoff (Max): 1µA (ICBO)
- DC Current Gain (hFE) (Min) @ Ic, Vce: 200 @ 100mA, 2V
- Power - Max: 3.5W
- Frequency - Transition: 380MHz
- Mounting Type: Surface Mount
- Package / Case: TO-243AA
- Supplier Device Package: PCP
- Base Part Number: 2SC5964
- detail: Bipolar (BJT) Transistor NPN 50V 3A 380MHz 3.5W Surface Mount PCP
