SB20-03P-TD-E Datasheet
Datasheet specifications
| Datasheet's name | SB20-03P-TD-E |
|---|---|
| File size | 54.748 KB |
| File type | |
| Number of pages | 6 |
Download Datasheet SB20-03P-TD-E |
Download Datasheet |
|---|
Other documentations
SB20-03P 6 pages
SB20-03P-TD-E 6 pages
Technical specifications
- RoHS: true
- Category: Diodes/Schottky Barrier Diodes (SBD)
- Datasheet: onsemi SB20-03P-TD-E
- Reverse Voltage (Vr): 30V
- Forward Voltage (Vf@If): 550mV@2A
- Reverse Leakage Current (Ir): 100uA@15V
- Average Rectified Current (Io): 2A
- Package: SOT-89
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 30V
- Current - Average Rectified (Io): 2A
- Voltage - Forward (Vf) (Max) @ If: 550mV @ 2A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 20ns
- Current - Reverse Leakage @ Vr: 100µA @ 15V
- Capacitance @ Vr, F: 70pF @ 10V, 1MHz
- Mounting Type: Surface Mount
- Package / Case: TO-243AA
- Supplier Device Package: PCP
- Operating Temperature - Junction: -55°C ~ 125°C
- Base Part Number: SB20
- detail: Diode Schottky 30V 2A Surface Mount PCP
