دیتاشیت CPH3215-TL-E
مشخصات دیتاشیت
| نام دیتاشیت |
CPH3115,3215
|
| حجم فایل |
643.419
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
7
|
مشخصات
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
-
Datasheet:
onsemi CPH3215-TL-E
-
Transistor Type:
NPN
-
Collector Current (Ic):
1.5A
-
Power Dissipation (Pd):
900mW
-
Transition Frequency (fT):
500MHz
-
DC Current Gain (hFE@Ic,Vce):
200@100mA,2V
-
Collector Cut-Off Current (Icbo):
100nA
-
Collector-Emitter Breakdown Voltage (Vceo):
30V
-
Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib):
225mV@15mA,750mA
-
Package:
SOT-23-3
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Current - Collector (Ic) (Max):
1.5A
-
Voltage - Collector Emitter Breakdown (Max):
30V
-
Vce Saturation (Max) @ Ib, Ic:
225mV @ 15mA, 750mA
-
Current - Collector Cutoff (Max):
100nA (ICBO)
-
DC Current Gain (hFE) (Min) @ Ic, Vce:
200 @ 100mA, 2V
-
Power - Max:
900mW
-
Frequency - Transition:
500MHz
-
Operating Temperature:
150°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
SC-96
-
Supplier Device Package:
3-CPH
-
Base Part Number:
CPH321
-
detail:
Bipolar (BJT) Transistor NPN 30V 1.5A 500MHz 900mW Surface Mount 3-CPH
