دیتاشیت ECH8663R-TL-H

ECH8663R

مشخصات دیتاشیت

نام دیتاشیت ECH8663R
حجم فایل 305.497 کیلوبایت
نوع فایل pdf
تعداد صفحات 7

دانلود دیتاشیت ECH8663R

ECH8663R Datasheet

مشخصات

  • RoHS: true
  • Type: 2 N-Channel
  • Category: Triode/MOS Tube/Transistor/MOSFETs
  • Datasheet: onsemi ECH8663R-TL-H
  • Power Dissipation (Pd): 1.5W
  • Total Gate Charge (Qg@Vgs): 12.3nC@4.5V
  • Drain Source Voltage (Vdss): 30V
  • Continuous Drain Current (Id): 8A
  • Drain Source On Resistance (RDS(on)@Vgs,Id): 20.5mΩ@4A,4.5V
  • Package: ECH-8
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • FET Type: 2 N-Channel (Dual)
  • FET Feature: Logic Level Gate
  • Drain to Source Voltage (Vdss): 30V
  • Current - Continuous Drain (Id) @ 25°C: 8A
  • Rds On (Max) @ Id, Vgs: 20.5mOhm @ 4A, 4.5V
  • Vgs(th) (Max) @ Id: -
  • Gate Charge (Qg) (Max) @ Vgs: 12.3nC @ 4.5V
  • Input Capacitance (Ciss) (Max) @ Vds: -
  • Power - Max: 1.5W
  • Operating Temperature: 150°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: 8-SMD, Flat Lead
  • Supplier Device Package: 8-ECH
  • Base Part Number: ECH8663
  • detail: Mosfet Array 2 N-Channel (Dual) 30V 8A 1.5W Surface Mount 8-ECH
