ADUM5010ARSZ-RL7 数据手册
其他文档
ADuM5010 16 pages
技术规格
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Datasheet: Analog Devices ADUM5010ARSZ-RL7
- Package: SSOP-20-208mil
- Manufacturer: Analog Devices
- Series: ADuM5010
- Packaging: Cut Tape (CT)
- Part Status: Active
- Type: Isolated Module
- Number of Outputs: 1
- Voltage - Input (Min): 3V
- Voltage - Input (Max): 5.5V
- Voltage - Output 1: 3.15 ~ 5.25V
- Voltage - Output 2: -
- Voltage - Output 3: -
- Current - Output (Max): 30mA
- Power (Watts): 150mW
- Voltage - Isolation: 2.5kV
- Applications: ITE (Commercial)
- Features: OTP, UVLO
- Operating Temperature: -40°C ~ 105°C
- Efficiency: -
- Mounting Type: Surface Mount
- Package / Case: 20-SSOP (0.209", 5.30mm Width)
- Size / Dimension: 0.28" L x 0.21" W x 0.07" H (7.2mm x 5.3mm x 1.9mm)
- Supplier Device Package: 20-SSOP
- Control Features: Enable, Active Low
- Base Part Number: ADUM5010
- detail: Isolated Module DC DC Converter 1 Output 3.15 ~ 5.25V 30mA 3V - 5.5V Input
