دیتاشیت PIC24FJ256GL405T-I/M4
مشخصات دیتاشیت
| نام دیتاشیت | PIC24FJ512GU410 Family~ |
|---|---|
| حجم فایل | 9896.15 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 1311 |
دانلود دیتاشیت PIC24FJ512GU410 Family~ |
PIC24FJ512GU410 Family~ Datasheet |
|---|
مشخصات
- CAN: -
- I2C: -
- I2S: -
- SPI: -
- RoHS: true
- EEPROM: -
- CPU Core: PIC
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: 32KB
- Watchdog: Yes
- ADC (Bit): -
- DAC (Bit): 10bit
- Datasheet: Microchip Tech PIC24FJ256GL405T-I/M4
- PWM (Bit): -
- 8Bit Timer: -
- UART/USART: -
- 16Bit Timer: -
- 32Bit Timer: -
- Real-Time Clock: -
- CPU Maximum Speed: 32MHz
- GPIO Ports Number: 39
- Low-Voltage Detect: -
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: IrDA;LIN(Local Interconnect Network);WDT;DMA;LCD/LED Driver;PWM
- Program Memory Type: FLASH
- Direct Memory Access: Yes
- Program Storage Size: 256KB
- Universal Serial Bus: -
- communication protocol: -
- Operating Voltage Range: 2V~3.6V
- Infrared Data Association: Yes
- Operating Temperature Range: -40°C~+85°C
- Secure Digital Input and Output: -
- Package: UQFN-48-EP(6x6)
- Manufacturer: Microchip Tech
- Series: Automotive, AEC-Q100, PIC® 24F
- Part Status: Active
- Core Processor: PIC
- Core Size: 16-Bit
- Speed: 32MHz
- Connectivity: I²C, IrDA, LINbus, SPI, UART/USART
- Peripherals: DMA, LCD, PWM, WDT
- Number of I/O: 39
- Program Memory Size: 256KB (256K x 8)
- EEPROM Size: -
- Voltage - Supply (Vcc/Vdd): 2V ~ 3.6V
- Data Converters: A/D 24x10/12b; D/A 1x10b
- Oscillator Type: External
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 48-UFQFN Exposed Pad
- Supplier Device Package: 48-UQFN (6x6)
- detail: PIC Automotive, AEC-Q100, PIC® 24F Microcontroller IC 16-Bit 32MHz 256KB (256K x 8) FLASH 48-UQFN (6x6)
