SMBJ6.8A 数据手册
技术规格
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/TVS
- Datasheet: KUU SMBJ6.8A
- Breakdown Voltage: 7.22V
- Maximum Clamping Voltage: 11.2V
- Reverse Leakage Current (Ir): 500uA
- Reverse Stand-Off Voltage (Vrwm): 6.8V
- Peak Pulse Current (Ipp)@10/1000us: 53.6A
- Package: SMB
- Manufacturer: KUU
- Peak Pulse Power Dissipation (Ppp)@10/1000us: 600W
- Part id: 1246167
