دیتاشیت MC74AC14DG
مشخصات دیتاشیت
| نام دیتاشیت |
MC74AC14DG
|
| حجم فایل |
73.848
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
9
|
مشخصات
-
RoHS:
true
-
Series:
74AC
-
Category:
Logic ICs/Inverters
-
Datasheet:
onsemi MC74AC14DG
-
Input Type:
-
-
Sink Current:
24mA
-
Source Current:
24mA
-
Number of Inputs:
6
-
Number of Circuits:
6
-
Supply Current (Max):
4uA
-
Low level range (VIL):
0.5V~1.1V
-
Max Propagation Delay:
10ns@5V,50pF
-
Operating Temperature:
-40°C~+85°C
-
High level range (VIH):
2.2V~3.9V
-
Supply Voltage(Single):
2V~6V
-
Package:
SOP-14
-
Manufacturer:
onsemi
