دیتاشیت BAT54SFILM
مشخصات دیتاشیت
| نام دیتاشیت | BAT54SFILM |
|---|---|
| حجم فایل | 55.626 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 15 |
BAT54SFILM |
دانلود دیتاشیت |
|---|
سایر مستندات
BAT54 Series Datasheet 15 pages
مشخصات فنی
- RoHS: true
- Category: Diodes/Schottky Barrier Diodes (SBD)
- Datasheet: STMicroelectronics BAT54SFILM
- Diode Configuration: Dual
- Reverse Voltage (Vr): 40V
- Forward Voltage (Vf@If): 900mV@100mA
- Reverse Leakage Current (Ir): 1uA@30V
- Average Rectified Current (Io): 300mA
- Package: SOT-23
- Manufacturer: STMicroelectronics
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Diode Type: Schottky
- Voltage - DC Reverse (Vr) (Max): 40V
- Current - Average Rectified (Io) (per Diode): 300mA (DC)
- Voltage - Forward (Vf) (Max) @ If: 900mV @ 100mA
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr): 5ns
- Current - Reverse Leakage @ Vr: 1µA @ 30V
- Operating Temperature - Junction: -40°C ~ 150°C
- Mounting Type: Surface Mount
- Package / Case: TO-236-3, SC-59, SOT-23-3
- Supplier Device Package: SOT-23-3
- Base Part Number: BAT54
- detail: Diode Array 1 Pair Series Connection Schottky 40V 300mA (DC) Surface Mount TO-236-3, SC-59, SOT-23-3
