规格
- RoHS true
- Category Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
- Datasheet Slkor(SLKORMICRO Elec.) 2SC1815
- Transistor Type NPN
- Operating Temperature -55°C~+150°C@(Tj)
- Collector Current (Ic) 0.15A
- Power Dissipation (Pd) 400mW
- Transition Frequency (fT) 80MHz
- Collector Cut-Off Current (Icbo) 100nA
- Collector-Emitter Breakdown Voltage (Vceo) 50V
- Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib) 250mV@100mA,10mA
- Package TO-92
- Manufacturer Slkor(SLKORMICRO Elec.)
- DC Current Gain (hFE@Ic,Vce) 200@2mA,6V
