MCP1525, MCP1541 Datasheet

MCP1525, MCP1541

Datasheet specifications

Datasheet's name MCP1525, MCP1541
File size 478.689 KB
File type pdf
Number of pages 20

Download Datasheet MCP1525, MCP1541

Download Datasheet

Other documentations

MCP1525T-I/TT 20 pages

Technical specifications

  • RoHS: true
  • Category: Power Supply Chip/Voltage References
  • Datasheet: Microchip Tech MCP1541T-I/TT
  • Tolerance: ±1%
  • Output Type: Fixed
  • Input Voltage: 4.3V~5.5V
  • Output Current: 2mA
  • Output Voltage: 4.096V
  • Reference Type: series connection
  • Supply Current: 120uA
  • Noise - 10Hz to 10kHz: 700uVrms
  • Operating Temperature: -40°C~+85°C@(Ta)
  • Temperature Coefficient: 50ppm/°C
  • Package: SOT-23(TO-236)
  • Manufacturer: Microchip Tech
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Voltage - Output (Min/Fixed): 4.096V
  • Current - Output: 2mA
  • Noise - 0.1Hz to 10Hz: 145µVp-p
  • Voltage - Input: 4.3V ~ 5.5V
  • Current - Supply: 120µA
  • Mounting Type: Surface Mount
  • Package / Case: TO-236-3, SC-59, SOT-23-3
  • Supplier Device Package: SOT-23-3
  • Base Part Number: MCP1541
  • detail: Series Voltage Reference IC ±1% SOT-23-3
