دیتاشیت 1.5KE36CA

1.5KE

مشخصات دیتاشیت

نام دیتاشیت 1.5KE
حجم فایل 140.351 کیلوبایت
نوع فایل pdf
تعداد صفحات 10

دانلود دیتاشیت 1.5KE

1.5KE Datasheet

مشخصات

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/TVS
  • Datasheet: Liown 1.5KE36CA
  • Breakdown Voltage: 34.2V
  • Maximum Clamping Voltage: 49.9V
  • Reverse Leakage Current (Ir): 1uA
  • Reverse Stand-Off Voltage (Vrwm): 30.8V
  • Peak Pulse Current (Ipp)@10/1000us: 30.5A
  • Peak Pulse Power Dissipation (Ppp)@10/1000us: 1500W
  • Package: DO-201
  • Manufacturer: Liown
  • Series: 1.5KE, TRANSIL™
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Type: Zener
  • Bidirectional Channels: 1
  • Voltage - Reverse Standoff (Typ): 30.8V
  • Voltage - Breakdown (Min): 34.2V
  • Voltage - Clamping (Max) @ Ipp: 64.3V
  • Current - Peak Pulse (10/1000µs): 156A (8/20µs)
  • Power - Peak Pulse: 1500W (1.5kW)
  • Power Line Protection: No
  • Applications: General Purpose
  • Capacitance @ Frequency: 1250pF @ 1MHz
  • Operating Temperature: -
  • Mounting Type: Through Hole
  • Package / Case: DO-201AA, DO-27, Axial
  • Supplier Device Package: DO-201
  • Base Part Number: 1.5KE
  • detail: 64.3V Clamp 156A (8/20µs) Ipp Tvs Diode Through Hole DO-201
