دیتاشیت MSRD620CTG
مشخصات دیتاشیت
| نام دیتاشیت | MSRD620CT, NRVSRD620VCT, SSRD8620CT Series |
|---|---|
| حجم فایل | 65.085 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 6 |
دانلود دیتاشیت MSRD620CT, NRVSRD620VCT, SSRD8620CT Series |
MSRD620CT, NRVSRD620VCT, SSRD8620CT Series Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Diodes/Switching Diode
- Datasheet: onsemi MSRD620CTG
- Power Dissipation: -
- Diode Configuration: Dual Common Cathode
- Reverse Voltage (Vr): 200V
- Operating Temperature: -55°C~+175°C@(Tj)
- Forward Voltage (Vf@If): 1.15V@3A
- Reverse Leakage Current: 5uA@200V
- Reverse Recovery Time (trr): 55ns
- Average Rectified Current (Io): 3A
- Package: TO-252
- Manufacturer: onsemi
- Series: SWITCHMODE™
- Packaging: Tube
- Part Status: Obsolete
- Diode Type: Standard
- Voltage - DC Reverse (Vr) (Max): 200V
- Current - Average Rectified (Io) (per Diode): 3A
- Voltage - Forward (Vf) (Max) @ If: 1.15V @ 3A
- Speed: Fast Recovery =< 500ns, > 200mA (Io)
- Current - Reverse Leakage @ Vr: 5µA @ 200V
- Operating Temperature - Junction: -55°C ~ 175°C
- Mounting Type: Surface Mount
- Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- Supplier Device Package: DPAK
- Base Part Number: MSRD6
- detail: Diode Array 1 Pair Common Cathode Standard 200V 3A Surface Mount TO-252-3, DPak (2 Leads + Tab), SC-63
