MUR420 数据手册
技术规格
- RoHS: true
- Category: Diodes/Diodes - Fast Recovery Rectifiers
- Datasheet: MDD(Microdiode Electronics) MUR420
- Package: DO-27
- Manufacturer: MDD(Microdiode Electronics)
- Diode Configuration: Single
- Reverse Voltage (Vr): 200V
- Operating Temperature: -55°C~+150°C@(Tj)
- Forward Voltage (Vf@If): 890mV@4A
- Reverse Leakage Current: 5uA@200V
- Reverse Recovery Time (trr): 25ns
- Average Rectified Current (Io): 4A
