دیتاشیت NCP1200P60

NCP1200 Series

مشخصات دیتاشیت

نام دیتاشیت NCP1200 Series
حجم فایل 287.934 کیلوبایت
نوع فایل pdf
تعداد صفحات 16

دانلود دیتاشیت NCP1200 Series

NCP1200 Series Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • Output Isolation: Isolated
  • Internal Switch(s): No
  • Voltage - Breakdown: -
  • Topology: Flyback
  • Voltage - Supply (Vcc/Vdd): 16V (Max)
  • Duty Cycle: 80%
  • Frequency - Switching: 60kHz
  • Fault Protection: Current Limiting, Over Load, Short Circuit
  • Control Features: -
  • Operating Temperature: -25°C ~ 125°C (TJ)
  • Package / Case: 8-DIP (0.300", 7.62mm)
  • Supplier Device Package: 8-PDIP
  • Mounting Type: Through Hole
  • Base Part Number: NCP1200
  • detail: Converter Offline Flyback Topology 60kHz 8-PDIP
