P6KE68CA 数据手册
技术规格
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/TVS
- Datasheet: Liown P6KE68CA
- Breakdown Voltage: 64.6V
- Maximum Clamping Voltage: 92V
- Reverse Leakage Current (Ir): 1uA
- Reverse Stand-Off Voltage (Vrwm): 58.1V
- Peak Pulse Current (Ipp)@10/1000us: 6.6A
- Peak Pulse Power Dissipation (Ppp)@10/1000us: 600W
- Package: DO-15
- Manufacturer: Liown
- Peak Pulse Current (Ipp)@10/1000μs: 6.5A
- Bidirectional Channels: 1
