دیتاشیت MOC3052M
مشخصات دیتاشیت
| نام دیتاشیت |
MOC3051M-53M
|
| حجم فایل |
424.974
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
13
|
مشخصات
-
RoHS:
true
-
Category:
Optocoupler/LED/Digital Tube/Photoelectric Device/Optocouplers - Thyristor Signal Output
-
SCR Type:
Two-way thyristor
-
Datasheet:
UMW(Youtai Semiconductor Co., Ltd.) MOC3052M
-
Forward Current:
60mA
-
Forward Voltage:
1.18V
-
Number of Outputs:
1
-
Operating Temperature:
-55°C~+100°C
-
Zero Crossing Circuit:
No
-
Isolation Voltage(rms):
5000V
-
Peak Off-state Voltage(Vdrm):
600V
-
RMS On-State Current(It(rms)):
100mA
-
Package:
DIP-6
-
Manufacturer:
UMW(Youtai Semiconductor Co., Ltd.)
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
Output Type:
Triac
-
Number of Channels:
1
-
Voltage - Isolation:
4170Vrms
-
Voltage - Off State:
600V
-
Static dV/dt (Min):
1kV/µs
-
Current - LED Trigger (Ift) (Max):
10mA
-
Current - Hold (Ih):
220µA (Typ)
-
Turn On Time:
-
-
Voltage - Forward (Vf) (Typ):
1.18V
-
Current - DC Forward (If) (Max):
60mA
-
Mounting Type:
Through Hole
-
Package / Case:
6-DIP (0.300", 7.62mm)
-
Supplier Device Package:
6-DIP
-
Approval Agency:
UR
-
Base Part Number:
MOC305
-
detail:
Optoisolator Triac Output 4170Vrms 1 Channel 6-DIP
