دیتاشیت NE5534DR
مشخصات دیتاشیت
| نام دیتاشیت | NE5534/A, SA5534/A |
|---|---|
| حجم فایل | 1361.596 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 27 |
دانلود دیتاشیت NE5534/A, SA5534/A |
NE5534/A, SA5534/A Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Operational Amplifier/Comparator/Operational Amplifier
- Datasheet: Texas Instruments NE5534DR
- -3db Bandwidth: -
- Output Current: 38mA
- Supply Current: 4mA
- Number of Circuits: 1
- Operating Temperature: 0°C~+70°C
- Current - Input Bias(Ib): 500nA
- Gain Bandwidth Product(GBP): 10MHz
- Package: SOP-8
- Manufacturer: Texas Instruments
- Current - Output / Channel: 38mA
- Slew Rate: 13V/µs
- Voltage - Input Offset: 500µV
- Part Status: Active
- Packaging: Cut Tape (CT)
- Supplier Device Package: 8-SOIC
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Voltage - Supply, Single/Dual (±): 10V ~ 30V, ±5V ~ 15V
- Series: -
- Output Type: -
- Base Part Number: NE5534
- Current - Supply: 4mA
- Mounting Type: Surface Mount
- Amplifier Type: General Purpose
- Current - Input Bias: 500nA
- Gain Bandwidth Product: 10MHz
- detail: General Purpose Amplifier 1 Circuit 8-SOIC
