دیتاشیت PIC24FJ32GB002-I/SP
مشخصات دیتاشیت
| نام دیتاشیت | PIC24FJ64GB004 Family |
|---|---|
| حجم فایل | 2845.639 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 352 |
دانلود دیتاشیت PIC24FJ64GB004 Family |
PIC24FJ64GB004 Family Datasheet |
|---|
مشخصات
- RoHS: true
- EEPROM: -
- CPU Core: PIC
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: 8KB
- Watchdog: Yes
- ADC (Bit): 10bit
- DAC (Bit): -
- Datasheet: Microchip Tech PIC24FJ32GB002-I/SP
- PWM (Bit): -
- Real-Time Clock: -
- CPU Maximum Speed: 32MHz
- GPIO Ports Number: 19
- Low-Voltage Detect: Yes
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: PWM
- Program Memory Type: FLASH
- Direct Memory Access: -
- Program Storage Size: 32KB
- Universal Serial Bus: Yes
- communication protocol: -
- Operating Voltage Range: 2V~3.6V
- Infrared Data Association: Yes
- Operating Temperature Range: -40°C~+85°C
- Secure Digital Input and Output: -
- Package: SPDIP-28
- Manufacturer: Microchip Tech
- Series: PIC® XLP™ 24F
- Packaging: Tube
- Part Status: Active
- Core Processor: PIC
- Core Size: 16-Bit
- Speed: 32MHz
- Connectivity: I²C, IrDA, SPI, UART/USART, USB OTG
- Peripherals: Brown-out Detect/Reset, LVD, POR, PWM, WDT
- Number of I/O: 19
- Program Memory Size: 32KB (11K x 24)
- EEPROM Size: -
- Voltage - Supply (Vcc/Vdd): 2V ~ 3.6V
- Data Converters: A/D 9x10b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Through Hole
- Package / Case: 28-DIP (0.300", 7.62mm)
- Supplier Device Package: 28-SPDIP
- Base Part Number: PIC24FJ32GB002
- detail: PIC PIC® XLP™ 24F Microcontroller IC 16-Bit 32MHz 32KB (11K x 24) FLASH 28-SPDIP
