- Datasheet IRFS3607TRLPBF
IRFB3607PBF Datasheet
Datasheet specifications
| Datasheet's name | IRFS3607TRLPBF |
|---|---|
| File size | 92.494 KB |
| File type | |
| Number of pages | 11 |
Download Datasheet IRFS3607TRLPBF |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- RoHS: true
- Type: N Channel
- Category: Triode/MOS Tube/Transistor/MOSFETs
- Datasheet: Infineon Technologies IRFB3607PBF
- Operating Temperature: -55°C~+175°C@(Tj)
- Power Dissipation (Pd): 140W
- Total Gate Charge (Qg@Vgs): 84nC@10V
- Drain Source Voltage (Vdss): 75V
- Input Capacitance (Ciss@Vds): 3070pF@50V
- Continuous Drain Current (Id): 80A
- Gate Threshold Voltage (Vgs(th)@Id): 4V@100uA
- Drain Source On Resistance (RDS(on)@Vgs,Id): 9mΩ@10V,46A
- Package: TO-220
- Manufacturer: Infineon Technologies
