دیتاشیت ISO3080DWR

مشخصات دیتاشیت

دانلود دیتاشیت ISO3080,82,86,88 Datasheet	ISO3080,82,86,88 Datasheet Datasheet

RoHS: true
Types: transceiver;隔离器
Category: Communication Interface Chip/UART/485/232/RS-485/RS-422 ICs
Data Rate: 200Kbps
Datasheet: Texas Instruments ISO3080DWR
Supply Voltage: 3.15V~5.5V
Driver/receiver: 2/2
Operating Temperature: -40°C~+85°C
Package: SOIC-16
Manufacturer: Texas Instruments
Type: RS422, RS485
Common Mode Transient Immunity (Min): 25kV/µs
Mounting Type: Surface Mount
Isolated Power: No
Voltage - Supply: 3.15V ~ 5.5V, 4.5V ~ 5.5V
Supplier Device Package: 16-SOIC
Part Status: Active
Base Part Number: ISO3080
Pulse Width Distortion (Max): -
Number of Channels: 3
Technology: Capacitive Coupling
Package / Case: 16-SOIC (0.295", 7.50mm Width)
Channel Type: Unidirectional
Inputs - Side 1/Side 2: 2/1
Rise / Fall Time (Typ): -
Series: -
Packaging: Cut Tape (CT)
Propagation Delay tpLH / tpHL (Max): -
Voltage - Isolation: 2500Vrms
detail: RS422, RS485 Digital Isolator 2500Vrms 3 Channel 200kbps 25kV/µs CMTI 16-SOIC (0.295", 7.50mm Width)
