دیتاشیت LP2951CMX/NOPB
مشخصات دیتاشیت
| نام دیتاشیت |
LP2950,51
|
| حجم فایل |
2306.575
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
55
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Texas Instruments LP2951CMX/NOPB
-
Output Type:
-
-
Output Current:
100mA
-
Output Voltage:
1.235V~29V
-
Dropout Voltage:
0.6V@(100mA)
-
Output Polarity:
positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
35V
-
Operating Temperature:
-40°C~+125°C@(Tj)
-
Quiescent Current (Ground Current):
120uA
-
Package:
SOP-8
-
Manufacturer:
Texas Instruments
-
Control Features:
Enable
-
Base Part Number:
LP2951
-
Package / Case:
8-SOIC (0.154", 3.90mm Width)
-
Current - Supply (Max):
14mA
-
Part Status:
Obsolete
-
Current - Output:
100mA
-
PSRR:
-
-
Series:
-
-
Voltage - Output (Min/Fixed):
1.235V (5V)
-
Mounting Type:
Surface Mount
-
Number of Regulators:
1
-
Current - Quiescent (Iq):
120µA
-
Output Configuration:
Positive
-
Voltage Dropout (Max):
0.6V @ 100mA
-
Supplier Device Package:
8-SOIC
-
Protection Features:
Over Current, Over Temperature, Short Circuit
-
Voltage - Input (Max):
30V
-
Packaging:
Cut Tape (CT)
-
Voltage - Output (Max):
29V
-
detail:
Linear Voltage Regulator IC 1 Output 100mA 8-SOIC
