دیتاشیت 74LCX14MX
مشخصات دیتاشیت
| نام دیتاشیت |
74LCX14
|
| حجم فایل |
1050.981
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
14
|
مشخصات
-
RoHS:
true
-
Category:
Logic ICs/Inverters
-
Datasheet:
onsemi 74LCX14MX
-
Input Type:
Schmitt Trigger
-
Sink Current:
24mA
-
Source Current:
24mA
-
Number of channels:
6
-
Supply Current (Max):
10uA
-
Low level range (VIL):
0.4V~0.6V
-
Max Propagation Delay:
6.5ns@3.3V,50pF
-
High level range (VIH):
1.7V~2.2V
-
Supply Voltage(Single):
2V~3.6V
-
Package:
SOP-14
-
Manufacturer:
onsemi
-
Series:
74LCX
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Logic Type:
Inverter
-
Number of Circuits:
6
-
Number of Inputs:
6
-
Features:
Schmitt Trigger
-
Voltage - Supply:
2V ~ 3.6V
-
Current - Quiescent (Max):
10µA
-
Current - Output High, Low:
24mA, 24mA
-
Logic Level - Low:
0.4V ~ 0.6V
-
Logic Level - High:
1.7V ~ 2.2V
-
Max Propagation Delay @ V, Max CL:
6.5ns @ 3.3V, 50pF
-
Operating Temperature:
-40°C ~ 85°C
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
14-SOIC
-
Package / Case:
14-SOIC (0.154", 3.90mm Width)
-
Base Part Number:
74LCX14
-
detail:
Inverter IC 6 Channel Schmitt Trigger 14-SOIC
