دیتاشیت NCH-RSL10-101Q48-ABG
مشخصات دیتاشیت
| نام دیتاشیت | RSL10 Datasheet |
|---|---|
| حجم فایل | 295.309 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 21 |
دانلود دیتاشیت RSL10 Datasheet |
RSL10 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Radio Frequency Chip/Antenna/RF Transceiver ICs
- Data Rate: 2Mbps
- Datasheet: onsemi NCH-RSL10-101Q48-ABG
- Interface: I2C,SPI,UART
- Applications: Bluetooth
- Frequency Range: 2.4GHz
- Receive Current: 3mA
- Operating Voltage: 3.3V
- Operating Temperature: -40°C~+85°C
- Current Of Transmitting: 12mA
- Package: QFN-48-EP(6x6)
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Type: TxRx + MCU
- RF Family/Standard: Bluetooth
- Protocol: Bluetooth v5.0
- Modulation: FSK, GFSK
- Frequency: 2.4GHz
- Data Rate (Max): 2Mbps
- Power - Output: 6dBm
- Sensitivity: -94dBm
- Memory Size: -
- Serial Interfaces: I²C, SPI, UART
- Voltage - Supply: 3.3V
- Current - Receiving: 3mA ~ 6.2mA
- Current - Transmitting: 12mA ~ 25mA
- Mounting Type: Surface Mount
- Package / Case: 48-VFQFN Exposed Pad
- Supplier Device Package: 48-QFN (6x6)
- Base Part Number: RSL1
- detail: IC RF TxRx + MCU Bluetooth Bluetooth v5.0 2.4GHz 48-VFQFN Exposed Pad
