SMCJ48A Datasheet

SMCJ48A

Datasheet specifications

Datasheet's name SMCJ48A
File size 70.658 KB
File type pdf
Number of pages 4

Download Datasheet SMCJ48A

Download Datasheet

Other documentations

SMCJ5.0A 4 pages

SMCJ5.0A 6 pages

SMCJ5.0A 5 pages

SMCJ24A 6 pages

SMCJ24A 4 pages

SMCJ24CA 7 pages

SMCJ24CA 4 pages

Technical specifications

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/TVS
  • Datasheet: Liown SMCJ48A
  • Breakdown Voltage: 53.3V
  • Maximum Clamping Voltage: 77.4V
  • Reverse Leakage Current (Ir): 1uA
  • Reverse Stand-Off Voltage (Vrwm): 48V
  • Peak Pulse Current (Ipp)@10/1000us: 19.4A
  • Peak Pulse Power Dissipation (Ppp)@10/1000us: 1500W
  • Package: SMC(DO-214AB)
  • Manufacturer: Liown
  • Unidirectional Channels: 1
  • Peak Pulse Current (Ipp)@10/1000μs: 19.4A
