SRV05-4HTG 数据手册
其他文档
SRV05-4HTG 4 pages
技术规格
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/TVS
- Datasheet: Littelfuse SRV05-4HTG
- Breakdown Voltage: -
- Unidirectional Channels: 4
- Maximum Clamping Voltage: 15V
- Reverse Stand-Off Voltage (Vrwm): 6V@Max
- Peak Pulse Current (Ipp)@10/1000us: 10A@8/20us
- Peak Pulse Power Dissipation (Ppp)@10/1000us: 150W
- Package: SOT-23-6
- Manufacturer: Littelfuse
- Reverse Leakage Current (Ir): 0.3uA
