AOD409 数据手册
其他文档
未找到其他文档！
技术规格
- RoHS: true
- Category: Triode/MOS Tube/Transistor/MOSFETs
- Package: TO-252
- Manufacturer: ISC
- Type: P Channel
- Datasheet: Alpha & Omega Semicon AOD409
- Operating Temperature: -55°C~+175°C@(Tj)
- Power Dissipation (Pd): 2.5W;60W
- Total Gate Charge (Qg@Vgs): 54nC@10V
- Drain Source Voltage (Vdss): 60V
- Input Capacitance (Ciss@Vds): 3600pF@30V
- Continuous Drain Current (Id): 26A
- Gate Threshold Voltage (Vgs(th)@Id): 2.4V@250uA
- Drain Source On Resistance (RDS(on)@Vgs,Id): 40mΩ@10V,20A
