دیتاشیت BC556B.
مشخصات دیتاشیت
| نام دیتاشیت |
BC556-60
|
| حجم فایل |
357.799
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
10
|
مشخصات
-
Manufacturer:
ON Semiconductor
-
Series:
-
-
Packaging:
Bulk
-
Part Status:
Obsolete
-
Transistor Type:
PNP
-
Current - Collector (Ic) (Max):
100mA
-
Voltage - Collector Emitter Breakdown (Max):
65V
-
Vce Saturation (Max) @ Ib, Ic:
650mV @ 5mA, 100mA
-
Current - Collector Cutoff (Max):
100nA
-
DC Current Gain (hFE) (Min) @ Ic, Vce:
180 @ 2mA, 5V
-
Power - Max:
625mW
-
Frequency - Transition:
280MHz
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Through Hole
-
Package / Case:
TO-226-3, TO-92-3 (TO-226AA)
-
Supplier Device Package:
TO-92-3
-
Base Part Number:
BC556
-
detail:
Bipolar (BJT) Transistor PNP 65V 100mA 280MHz 625mW Through Hole TO-92-3
