CSD17575Q3 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
CSD17575Q3
|
|
حجم فایل
|
72.988
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
17
|
مشخصات فنی
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
Texas Instruments CSD17575Q3
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Power Dissipation (Pd):
2.8W;108W
-
Total Gate Charge (Qg@Vgs):
30nC@4.5V
-
Drain Source Voltage (Vdss):
30V
-
Input Capacitance (Ciss@Vds):
4420pF@15V
-
Continuous Drain Current (Id):
60A
-
Gate Threshold Voltage (Vgs(th)@Id):
1.8V@250uA
-
Reverse Transfer Capacitance (Crss@Vds):
-
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
2.3mΩ@25A,10V
-
Package:
VSON-CLIP-8(3.3x3.3)
-
Manufacturer:
Texas Instruments
