دیتاشیت IXTT1N450HV*
مشخصات دیتاشیت
| نام دیتاشیت |
IXTT1N450HV
|
| حجم فایل |
219.251
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
6
|
مشخصات
-
Manufacturer:
IXYS
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
FET Type:
N-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
4500V
-
Current - Continuous Drain (Id) @ 25°C:
1A (Tc)
-
Drive Voltage (Max Rds On, Min Rds On):
10V
-
Rds On (Max) @ Id, Vgs:
85Ohm @ 50mA, 10V
-
Vgs(th) (Max) @ Id:
6.5V @ 250µA
-
Gate Charge (Qg) (Max) @ Vgs:
40nC @ 10V
-
Vgs (Max):
±20V
-
Input Capacitance (Ciss) (Max) @ Vds:
1730pF @ 25V
-
FET Feature:
-
-
Power Dissipation (Max):
520W (Tc)
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
TO-268
-
Package / Case:
TO-268-3, D³Pak (2 Leads + Tab), TO-268AA
-
detail:
N-Channel 4500V 1A (Tc) 520W (Tc) Surface Mount TO-268
