دیتاشیت ISL9V5036S3S*

ISL9V5036S3S/P3/S3

مشخصات دیتاشیت

نام دیتاشیت ISL9V5036S3S/P3/S3
حجم فایل 434.297 کیلوبایت
نوع فایل pdf
تعداد صفحات 8

دانلود دیتاشیت ISL9V5036S3S/P3/S3

ISL9V5036S3S/P3/S3 Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: EcoSPARK®
  • Packaging: Tube
  • Part Status: Obsolete
  • IGBT Type: -
  • Voltage - Collector Emitter Breakdown (Max): 390V
  • Current - Collector (Ic) (Max): 46A
  • Vce(on) (Max) @ Vge, Ic: 1.6V @ 4V, 10A
  • Power - Max: 250W
  • Switching Energy: -
  • Input Type: Logic
  • Gate Charge: 32nC
  • Td (on/off) @ 25°C: -/10.8µs
  • Test Condition: 300V, 1kOhm, 5V
  • Operating Temperature: -40°C ~ 175°C (TJ)
  • Mounting Type: Through Hole
  • Package / Case: TO-262-3 Long Leads, I²Pak, TO-262AA
  • Supplier Device Package: TO-262AA
  • Base Part Number: ISL9
  • detail: IGBT 390V 46A 250W Through Hole TO-262AA
