MAX17682ATP+ دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت MAX17682ATP+	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: Step-down
Datasheet: Analog Devices Inc./Maxim Integrated MAX17682ATP+
Output Type: Fixed
Input Voltage: 4.5V~42V
Output Voltage: 5V
Number of Outputs: 1
Switching Frequency: 500kHz
Output Current (Max): 3.7A
Operating Temperature: -40°C~+125°C@(TA)
Synchronous Rectification: Yes
Package: QFN-20-EP(4x4)
Manufacturer: Analog Devices Inc./Maxim Integrated
Voltage - Input (Max): 42V
Voltage - Input (Min): 4.5V
Output Configuration: Positive, Isolation Capable
Supplier Device Package: 20-TQFN (4x4)
Package / Case: 20-WFQFN Exposed Pad
Frequency - Switching: 100kHz ~ 500kHz
Current - Output: 3.7A
Part Status: Active
Series: -
Voltage - Output (Max): -
Base Part Number: MAX17682
Mounting Type: Surface Mount
Synchronous Rectifier: Yes
Voltage - Output (Min/Fixed): 5V
Packaging: Tube
detail: Buck Switching Regulator IC Positive, Isolation Capable Fixed 5V 1 Output 3.7A 20-WFQFN Exposed Pad
