دیتاشیت RB520S30T5G

RB520S30

مشخصات دیتاشیت

نام دیتاشیت RB520S30
حجم فایل 319.659 کیلوبایت
نوع فایل pdf
تعداد صفحات 7

دانلود دیتاشیت RB520S30

RB520S30 Datasheet

مشخصات

  • RoHS: true
  • Category: Diodes/Schottky Barrier Diodes (SBD)
  • Datasheet: onsemi RB520S30T5G
  • Reverse Voltage (Vr): 30V
  • Forward Voltage (Vf@If): 600mV@200mA
  • Reverse Leakage Current (Ir): 1uA@10V
  • Average Rectified Current (Io): 200mA
  • Package: SOD-523
  • Manufacturer: onsemi
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Obsolete
  • Diode Type: Schottky
  • Voltage - DC Reverse (Vr) (Max): 30V
  • Current - Average Rectified (Io): 200mA
  • Voltage - Forward (Vf) (Max) @ If: 600mV @ 200mA
  • Speed: Small Signal =< 200mA (Io), Any Speed
  • Current - Reverse Leakage @ Vr: 1µA @ 10V
  • Capacitance @ Vr, F: -
  • Mounting Type: Surface Mount
  • Package / Case: SC-79, SOD-523F
  • Supplier Device Package: SOD-523F
  • Operating Temperature - Junction: -55°C ~ 125°C
  • Base Part Number: RB520
  • detail: Diode Schottky 30V 200mA Surface Mount SOD-523F
