دیتاشیت FFSP2065B-F085

FFSP2065B-F085

مشخصات دیتاشیت

نام دیتاشیت FFSP2065B-F085
حجم فایل 217.859 کیلوبایت
نوع فایل pdf
تعداد صفحات 6

دانلود دیتاشیت FFSP2065B-F085

FFSP2065B-F085 Datasheet

مشخصات

  • RoHS: true
  • Category: Diodes/Schottky Barrier Diodes (SBD)
  • Datasheet: onsemi FFSP2065B-F085
  • Diode Configuration: Dual Common Cathode
  • Reverse Voltage (Vr): 650V
  • Forward Voltage (Vf@If): 1.38V@10A
  • Reverse Leakage Current (Ir): 500nA@650V
  • Average Rectified Current (Io): 10A
  • Package: TO-220-2
  • Manufacturer: onsemi
  • Series: Automotive, AEC-Q101
  • Part Status: Active
  • Diode Type: Silicon Carbide Schottky
  • Voltage - DC Reverse (Vr) (Max): 650V
  • Current - Average Rectified (Io): 20A
  • Voltage - Forward (Vf) (Max) @ If: 1.7V @ 20A
  • Speed: No Recovery Time > 500mA (Io)
  • Reverse Recovery Time (trr): 0ns
  • Current - Reverse Leakage @ Vr: 40µA @ 650V
  • Capacitance @ Vr, F: 866pF @ 1V, 100kHz
  • Mounting Type: Through Hole
  • Package / Case: TO-220-2
  • Supplier Device Package: TO-220-2
  • Operating Temperature - Junction: -55°C ~ 175°C
  • Base Part Number: FFSP20
  • detail: Diode Silicon Carbide Schottky 650V 20A Through Hole TO-220-2
