PZT3906* 数据手册
数据手册规格
| 数据手册名称 | 2N3906, MMBT3906, PZT3906 |
|---|---|
| 文件大小 | 515.535 千字节 |
| 文件类型 | |
| 页数 | 11 |
下载数据手册 2N3906, MMBT3906, PZT3906 |
下载数据手册 |
|---|
其他文档
未找到其他文档！
技术规格
- Manufacturer: ON Semiconductor
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Obsolete
- Transistor Type: PNP
- Current - Collector (Ic) (Max): 200mA
- Voltage - Collector Emitter Breakdown (Max): 40V
- Vce Saturation (Max) @ Ib, Ic: 400mV @ 5mA, 50mA
- Current - Collector Cutoff (Max): -
- DC Current Gain (hFE) (Min) @ Ic, Vce: 100 @ 10mA, 1V
- Power - Max: 1W
- Frequency - Transition: 250MHz
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: TO-261-4, TO-261AA
- Supplier Device Package: SOT-223-4
- Base Part Number: PZT390
- detail: Bipolar (BJT) Transistor PNP 40V 200mA 250MHz 1W Surface Mount SOT-223-4
