دیتاشیت LM2904DR2G
مشخصات دیتاشیت
| نام دیتاشیت | LM258, 358(A), 2904 (A,V), NCV2904 Datasheet |
|---|---|
| حجم فایل | 386.354 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 16 |
دانلود دیتاشیت LM258, 358(A), 2904 (A,V), NCV2904 Datasheet |
LM258, 358(A), 2904 (A,V), NCV2904 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Operational Amplifier/Comparator/Operational Amplifier
- Datasheet: onsemi LM2904DR2G
- -3db Bandwidth: -
- Output Current: 40mA
- Supply Current: 1.5mA
- Number of Circuits: 2
- Operating Temperature: -40°C~+85°C
- Current - Input Bias(Ib): 45nA
- Gain Bandwidth Product(GBP): 1MHz
- Package: SOP-8
- Manufacturer: onsemi
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Obsolete
- Amplifier Type: General Purpose
- Output Type: -
- Slew Rate: 0.6V/µs
- Gain Bandwidth Product: 1MHz
- Current - Input Bias: 45nA
- Voltage - Input Offset: 2mV
- Current - Supply: 1.5mA
- Current - Output / Channel: 40mA
- Voltage - Supply, Single/Dual (±): 3V ~ 32V, ±1.5V ~ 16V
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 8-SOIC
- Base Part Number: LM2904
- detail: General Purpose Amplifier 2 Circuit 8-SOIC
