دیتاشیت DS1302SN+

مشخصات دیتاشیت

دانلود دیتاشیت DS1302	DS1302 Datasheet

Features: Leap Year, NVSRAM, Trickle-Charger
Supplier Device Package: 8-SO
Voltage - Supply, Battery: 2V ~ 5.5V
Date Format: YY-MM-DD-dd
Memory Size: 31B
Part Status: Obsolete
Operating Temperature: -40°C ~ 85°C
Type: Clock/Calendar
Series: -
Interface: 3-Wire Serial
Time Format: HH:MM:SS (12/24 hr)
Mounting Type: Surface Mount
Package / Case: 8-SOIC (0.209", 5.30mm Width)
Current - Timekeeping (Max): 0.3µA ~ 1µA @ 2V ~ 5V
Packaging: Tube
Voltage - Supply: 2V ~ 5.5V
Base Part Number: DS1302
Manufacturer: Maxim Integrated
detail: Real Time Clock (RTC) IC Clock/Calendar 31B 3-Wire Serial 8-SOIC (0.209", 5.30mm Width)
