دیتاشیت HCF4013YM013TR

مشخصات دیتاشیت

دانلود دیتاشیت HCF4013B	HCF4013B Datasheet

Manufacturer: STMicroelectronics
Series: Automotive, AEC-Q100, 4000
Packaging: Cut Tape (CT)
Part Status: Active
Function: Set(Preset) and Reset
Type: D-Type
Output Type: Differential
Number of Elements: 2
Number of Bits per Element: 1
Clock Frequency: 24MHz
Max Propagation Delay @ V, Max CL: 90ns @ 15V, 50pF
Trigger Type: Positive Edge
Current - Output High, Low: 6.8mA, 6.8mA
Voltage - Supply: 3V ~ 20V
Current - Quiescent (Iq): 20µA
Input Capacitance: 5pF
Operating Temperature: -40°C ~ 125°C (TA)
Mounting Type: Surface Mount
Supplier Device Package: 14-SO
Package / Case: 14-SOIC (0.154", 3.90mm Width)
Base Part Number: HCF4013
detail: Flip Flop 2 Element D-Type 1 Bit Positive Edge 14-SOIC (0.154", 3.90mm Width)
