دیتاشیت FFA60UP30DNTU
مشخصات دیتاشیت
| نام دیتاشیت |
FFA60UP30DN
|
| حجم فایل |
954.526
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
7
|
مشخصات
-
RoHS:
true
-
Category:
Diodes/Diodes - Fast Recovery Rectifiers
-
Datasheet:
onsemi FFA60UP30DNTU
-
Diode Configuration:
Dual Common Cathode
-
Reverse Voltage (Vr):
300V
-
Operating Temperature:
-65°C~+150°C@(Tj)
-
Forward Voltage (Vf@If):
1.5V@30A
-
Reverse Leakage Current:
100uA@300V
-
Reverse Recovery Time (trr):
55ns
-
Average Rectified Current (Io):
30A
-
Package:
TO-3P
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
Diode Type:
Standard
-
Voltage - DC Reverse (Vr) (Max):
300V
-
Current - Average Rectified (Io) (per Diode):
30A
-
Voltage - Forward (Vf) (Max) @ If:
1.5V @ 30A
-
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
-
Current - Reverse Leakage @ Vr:
100µA @ 300V
-
Operating Temperature - Junction:
-65°C ~ 150°C
-
Mounting Type:
Through Hole
-
Package / Case:
TO-3P-3, SC-65-3
-
Supplier Device Package:
TO-3P
-
Base Part Number:
FFA60
-
detail:
Diode Array 1 Pair Common Cathode Standard 300V 30A Through Hole TO-3P-3, SC-65-3
