AD7190 Datasheet
Datasheet specifications
| Datasheet's name | AD7190 |
|---|---|
| File size | 661.794 KB |
| File type | |
| Number of pages | 40 |
Download Datasheet AD7190 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: Analog Devices Inc.
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Number of Bits: 24
- Sampling Rate (Per Second): -
- Number of Inputs: 2, 4
- Input Type: Differential, Pseudo-Differential
- Data Interface: SPI, DSP
- Configuration: MUX-PGA-ADC
- Ratio - S/H:ADC: -
- Number of A/D Converters: 1
- Architecture: Sigma-Delta
- Reference Type: External
- Voltage - Supply, Analog: 5V
- Voltage - Supply, Digital: 2.7V ~ 5.25V
- Features: PGA
- Operating Temperature: -40°C ~ 105°C
- Package / Case: 24-TSSOP (0.173", 4.40mm Width)
- Supplier Device Package: 24-TSSOP
- Mounting Type: Surface Mount
- Base Part Number: AD7190
- detail: 24 Bit Analog to Digital Converter 2, 4 Input 1 Sigma-Delta 24-TSSOP
