ADS1232, ADS1234 Datasheet

مشخصات دیتاشیت

نام دیتاشیت ADS1232, ADS1234 Datasheet
حجم فایل 1252.518 کیلوبایت
نوع فایل pdf
تعداد صفحات 39

دانلود دیتاشیت ADS1232, ADS1234 Datasheet

ADS1232, ADS1234 Datasheet Datasheet

مشخصات

  • Configuration: MUX-PGA-ADC
  • Voltage - Supply, Analog: 2.7V ~ 5.3V
  • Base Part Number: ADS1232
  • Operating Temperature: -40°C ~ 105°C
  • Voltage - Supply, Digital: 2.7V ~ 5.3V
  • Number of Bits: 24
  • Series: -
  • Package / Case: 24-TSSOP (0.173", 4.40mm Width)
  • Packaging: Tape & Reel (TR)
  • Supplier Device Package: 24-TSSOP
  • Number of Inputs: 2
  • Ratio - S/H:ADC: -
  • Reference Type: External
  • Mounting Type: Surface Mount
  • Part Status: Active
  • Sampling Rate (Per Second): 80
  • Manufacturer: Texas Instruments
  • Number of A/D Converters: 1
  • Data Interface: SPI
  • Architecture: Sigma-Delta
  • Input Type: Differential, Single Ended
  • Features: PGA
  • detail: 24 Bit Analog to Digital Converter 2 Input 1 Sigma-Delta 24-TSSOP
