دیتاشیت OptoCoupler HCPL2630SD Logic Output SMD8 | 00

6N137, HCPL2601,11,30,31

مشخصات دیتاشیت

نام دیتاشیت 6N137, HCPL2601,11,30,31
حجم فایل 1368.645 کیلوبایت
نوع فایل pdf
تعداد صفحات 15

دانلود دیتاشیت 6N137, HCPL2601,11,30,31

6N137, HCPL2601,11,30,31 Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Number of Channels: 2
  • Inputs - Side 1/Side 2: 2/0
  • Voltage - Isolation: 2500Vrms
  • Common Mode Transient Immunity (Min): 10kV/µs (Typ)
  • Input Type: DC
  • Output Type: Open Collector
  • Current - Output / Channel: 50mA
  • Data Rate: 10Mbps
  • Propagation Delay tpLH / tpHL (Max): 75ns, 75ns
  • Rise / Fall Time (Typ): 50ns, 12ns
  • Voltage - Forward (Vf) (Typ): 1.4V
  • Current - DC Forward (If) (Max): 30mA
  • Voltage - Supply: 4.5V ~ 5.5V
  • Operating Temperature: -40°C ~ 85°C
  • Mounting Type: Surface Mount
  • Package / Case: 8-SMD, Gull Wing
  • Supplier Device Package: 8-SMD
  • Base Part Number: HCPL26
  • detail: Logic Output Optoisolator 10Mbps Open Collector 2500Vrms 2 Channel 10kV/µs (Typ) CMTI 8-SMD
