دیتاشیت STGW20NC60VD

STGW20NC60VD

مشخصات دیتاشیت

نام دیتاشیت STGW20NC60VD
حجم فایل 348.127 کیلوبایت
نوع فایل pdf
تعداد صفحات 14

دانلود دیتاشیت STGW20NC60VD

STGW20NC60VD Datasheet

مشخصات

  • Manufacturer: STMicroelectronics
  • Series: PowerMESH™
  • Packaging: Tube
  • Part Status: Active
  • IGBT Type: -
  • Voltage - Collector Emitter Breakdown (Max): 600V
  • Current - Collector (Ic) (Max): 60A
  • Current - Collector Pulsed (Icm): 150A
  • Vce(on) (Max) @ Vge, Ic: 2.5V @ 15V, 20A
  • Power - Max: 200W
  • Switching Energy: 220µJ (on), 330µJ (off)
  • Input Type: Standard
  • Gate Charge: 100nC
  • Td (on/off) @ 25°C: 31ns/100ns
  • Test Condition: 390V, 20A, 3.3Ohm, 15V
  • Reverse Recovery Time (trr): 44ns
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Through Hole
  • Package / Case: TO-247-3
  • Supplier Device Package: TO-247-3
  • Base Part Number: STGW20
  • detail: IGBT 600V 60A 200W Through Hole TO-247-3
