SMCJ30A 数据手册
技术规格
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/TVS
- Datasheet: PAKER SMCJ30A
- Breakdown Voltage: 33.3V
- Maximum Clamping Voltage: 48.4V
- Reverse Leakage Current (Ir): 1uA
- Reverse Stand-Off Voltage (Vrwm): 30V
- Peak Pulse Current (Ipp)@10/1000us: 31A
- Peak Pulse Power Dissipation (Ppp)@10/1000us: 1500W
- Package: SMC(DO-214AB)
- Manufacturer: PAKER
- Unidirectional Channels: 1
- Peak Pulse Current (Ipp)@10/1000μs: 30.99A
