US1G 数据手册
技术规格
- RoHS: true
- Category: Diodes/Diodes - Fast Recovery Rectifiers
- Datasheet: YFW US1G
- Diode Configuration: Single
- Reverse Voltage (Vr): 400V
- Operating Temperature: -55°C~+150°C@(Tj)
- Forward Voltage (Vf@If): 1.25V@1A
- Reverse Leakage Current: 5uA@400V
- Reverse Recovery Time (trr): 50ns
- Average Rectified Current (Io): 1A
- Package: SMA
- Manufacturer: YFW
- Reverse Leakage Current (Ir): 5uA@400V
