TPD6F002DSVR دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت TPD6F002DSVR	دانلود دیتاشیت

TPD6F002 18 pages

RoHS: true
Category: Bead/Filter/EMI Optimization/EMI Filters (LC, RC Networks)
Datasheet: Texas Instruments TPD6F002DSVR
Inductance: -
Resistance: 100Ω
Capacitance: 17pF
Filter Order: 2
Rated Current: -
ESD Protection: Yes
DC Rated Voltage: -
Attenuation Value: 57dB@100MHz
Number of Channels: 6
OperatingTemperature: -40°C~+85°C
Frequency - Cutoff or Center: 100MHz
Package: DFN-12(1.4x3)
Manufacturer: Texas Instruments
Type: Low Pass
Operating Temperature: -40°C ~ 85°C
Packaging: Cut Tape (CT)
Package / Case: 12-WFDFN Exposed Pad
Voltage - Rated: -
Technology: RC (Pi)
Size / Dimension: 0.118" L x 0.053" W (3.00mm x 1.35mm)
Center / Cutoff Frequency: 100MHz (Cutoff)
Height: 0.031" (0.79mm)
Mounting Type: Surface Mount
Part Status: Active
Series: TPD
Applications: Data Lines for Mobile Devices
Base Part Number: TPD6F0
Resistance - Channel (Ohms): 100
Values: R = 100Ohms, C = 17pF
detail: RC (Pi) EMI Filter 2nd Order Low Pass 6 Channel R = 100Ohms, C = 17pF 12-WFDFN Exposed Pad
