- دیتاشیت ADF7020-1BCPZ-RL7
دیتاشیت ADF7020-1BCPZ-RL7
مشخصات دیتاشیت
| نام دیتاشیت | ADF7020-1BCPZ-RL7 |
|---|---|
| حجم فایل | 85.101 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 45 |
ADF7020-1BCPZ-RL7 |
دانلود دیتاشیت |
|---|
سایر مستندات
ADF7020-1 45 pages
مشخصات فنی
- RoHS: true
- Category: Radio Frequency Chip/Antenna/RF Transceiver ICs
- Datasheet: Analog Devices ADF7020-1BCPZ-RL7
- Package: LFCSP-48-EP(7x7)
- Manufacturer: Analog Devices
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Type: TxRx Only
- RF Family/Standard: VHF
- Protocol: FM Radio
- Modulation: ASK, FSK, GFSK, GOOK, OOK
- Frequency: 80MHz ~ 650MHz
- Data Rate (Max): 200kbps
- Power - Output: 13dBm (Max)
- Sensitivity: -119.2dBm
- Memory Size: -
- Serial Interfaces: SPI
- Voltage - Supply: 2.3V ~ 3.6V
- Current - Receiving: 17.6mA ~ 20.1mA
- Current - Transmitting: 13mA ~ 21mA
- Operating Temperature: -40°C ~ 85°C
- Mounting Type: Surface Mount
- Package / Case: 48-VFQFN Exposed Pad, CSP
- Supplier Device Package: 48-LFCSP (7x7)
- Base Part Number: ADF7020
- detail: IC RF TxRx Only VHF FM Radio 80MHz ~ 650MHz 48-VFQFN Exposed Pad, CSP
