دیتاشیت DMG3420U-7
مشخصات دیتاشیت
| نام دیتاشیت |
DMG3420U-7
|
| حجم فایل |
107.243
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
6
|
مشخصات
-
RoHS:
true
-
Type:
N Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
Diodes Incorporated DMG3420U-7
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Power Dissipation (Pd):
740mW
-
Total Gate Charge (Qg@Vgs):
5.4nC@4.5V
-
Drain Source Voltage (Vdss):
20V
-
Input Capacitance (Ciss@Vds):
434.7pF@10V
-
Continuous Drain Current (Id):
5.47A
-
Gate Threshold Voltage (Vgs(th)@Id):
1.2V@250uA
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
29mΩ@10V,6A
-
Package:
SOT-23
-
Manufacturer:
Diodes Incorporated
