دیتاشیت ESDA5V3L

ESDAxxL

مشخصات دیتاشیت

نام دیتاشیت ESDAxxL
حجم فایل 200.22 کیلوبایت
نوع فایل pdf
تعداد صفحات 11

دانلود دیتاشیت ESDAxxL

ESDAxxL Datasheet

مشخصات

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
  • Datasheet: TECH PUBLIC ESDA5V3L
  • Package: SOT-23-3
  • Manufacturer: TECH PUBLIC
  • Clamping Voltage@Ipp: 16V
  • Breakdown Voltage (VBR): 4V
  • Peak Pulse Current(Ipp)@8/20us: 24A
  • Reverse Stand-Off Voltage (Vrwm): 3V
  • Number of Lines: 2
  • Operating Temperature: -40°C~+125°C@(Tj)
  • Peak Pulse Power(Ppp)@8/20us: 300W
  • Series: ESDA, TRANSIL™
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Type: Zener
  • Unidirectional Channels: 2
  • Voltage - Reverse Standoff (Typ): 3V
  • Voltage - Breakdown (Min): 5.3V
  • Voltage - Clamping (Max) @ Ipp: -
  • Current - Peak Pulse (10/1000µs): -
  • Power - Peak Pulse: 300W
  • Power Line Protection: No
  • Applications: General Purpose
  • Capacitance @ Frequency: -
  • Mounting Type: Surface Mount
  • Package / Case: TO-236-3, SC-59, SOT-23-3
  • Supplier Device Package: SOT-23-3
  • Base Part Number: ESDA5
  • detail: Clamp Ipp Tvs Diode Surface Mount SOT-23-3
